Metro Sign Build: Bringing it All Together

Build Log 6: The While Loop

The time has come for us to put our pieces together and get something running! As a quick refresh, we now have:

1. A way to display text on our panels

2. A way to connect to the internet to get train data

3. A way to store the train data we want to show on the panels

All we need is the connecting code to get everything working together. This is actually pretty simple to get to a functional stage. Still, the true magic comes in the quality-of-life features we can add once we’ve validated that all the pieces are functioning and communicating as intended. Let’s get that started!

The While Loop

Keeping things Constant

The beating heart of our entire code is this While loop. After initialization, every moment of time is spent somewhere in this while loop. To that end, we’re going to use a While True loop to keep in a perpetual loop state; we’ll add each function we need to run into the loop, then set the appropriate interval or checks for that action to run. This allows us to really customize what happens within the loop while still making it easy to keep the code running and the sign still working!

The first thing we want to do is set up a couple of constants we’ll be using:

1. loop_counter: this isn’t technically necessary, but it can be helpful for determining how long the code has been looping and troubleshooting

2. Time checks: the core way we check if functions should run is through. time checks. You could do this through the loop_counter instead, but I was willing to sacrifice the simplicity to know exactly when we last executed each major function. This time check ensures that everything doesn’t run every loop, but at a frequency we control.

I’ll admit that neither of these is totally necessary right now as I doubt you’ll run out of WMATA API calls, but the more we can implement basic protocols now to save us some headaches down the line the better. This is part of the careful balancing act present in any MVP: how do we build as little as possible to make sure we’re on the right path, but enough that we don’t have to rip everything out and start from scratch on the next iteration?

One final note: when we initially declare these variables, we’ll want to start loop_counter at 1 (to indicate the first loop) and last_train_check at None, since we haven’t filled this variable yet. More on that later!

Building the Loop

For all the fanfare, this is actually really simple:

1. After establishing the constants, we start the loop.

2. Once in the loop, we review the check constants for each function to run.

3. If the conditions are met, we run the function.

4. If we’re happy with what we got, we reset the check constants.

5. We refresh the display.

6. We run garbage collection to keep our available memory ship shape.

7. We sleep the while loop for a bit.

Let’s dive into the more complex steps 2-4 to get our functions working.

Keeping Time

The way we use the check constant here is through the time.monotonic() method. This is a really neat way to handle relative time change; we don’t care if we run our train API calls at a specific time, we care about running them at a specific cadence. time.monotonic() is perfect for this because it basically starts a running timer; GPT-4 describes it as “a method in the time module of Python that returns the current value of a clock that counts up at a constant rate.“ We can define a certain amount of time we want to wait between running a function, which we’ll call an interval variable, then see if that amount of time has elapsed by comparing our current time.monotonic() to our check constant plus that interval variable. This is how it looks in the code:

# update train data (default: 15 seconds)
if last_train_check is None or time.monotonic() > last_train_check + 15:
    trains = get_trains(station_code, historical_trains)
    if trains:
        last_train_check = time.monotonic()
    # update train display component
    display_manager.update_trains(trains, historical_trains)

The first check is for startup conditions where we’ve never run the loop before so our constant is None, and the second is our comparing our current time.monotonic() against our check constant and interval variable. If either of those conditions is met, we get fresh train data.

One key point here is around the refreshing of the check constant: if we don’t get train objects returned from the get_trains function, we don’t reset the last_train_check constant. We’re not going to do anything with this right away as with this shorter interval variable it doesn’t matter, but we can come up with more versatile handling in the future if we notice we’re not getting train objects.

Speaking of missing train objects, let’s assume it’s been 15 seconds since we refreshed train data, so we refresh the train data again; the good part about how we’ve been designing our display functions is that they don’t trust our data collection functions, so it doesn’t matter if we get train objects back or not–we know the display manager can handle it, so we can run it every time we run our get_trains function.

Wrapping Things Up

Now that we have the hard part taken care of, we can do a few chores before wrapping up our loop.

1. Refresh our display: it doesn’t matter how many functions we run in our core While loop if we don’t push any of those changes to our display. Refreshing our display at the end of the loop makes 100% sure that any changes we’ve made to the user-facing side of things go live, even if we do our best to update the display through the display manager side.

2. Collect our garbage: we’ve known from the beginning that we’re working with very limited memory on the Matrix Portal, so let’s do our part and clean up after ourselves after each loop. We’ll also print this out along with our loop iteration so we can keep an eye on long-term memory allocation.

3. Sleep our loop: Given that we’re using our time.monotonic() checks I don’t think this is completely necessary, but this put the loop cadence under our control rather than leaving it up to how fast the Portal can run through the While loop. We don’t need it to run as quickly as possible, so let’s give the Portal a break and only run the loop every 10 seconds. The core thing to remember here is that every check constant will have to be greater than the loop sleep period for that check to actually work properly. Some things we may want to run every loop, like our train functions, but that might not always be the case!

Here’s how all that looks in the code:

# refresh display
display_manager.refresh_display()
# run garbage collection
gc.collect()
# print available memory
print("Loop {} | Available memory: {} bytes".format(loop_counter, gc.mem_free()))
loop_counter+=1
time.sleep(10)

Conclusion

We built our loop! With all of this together, we should have a functioning loop where the get_trains function is periodically called, the display_manager updates the panels, and fresh train data is displayed. Let’s quickly revisit our MVP objective:

Create an LED sign that displays the time to arrival for incoming trains at my local Metro station.

As of this point, we can declare the mission accomplished! I think this is a reasonable v0.8, and you can see the project at that point in our v0.8 release on GitHub. However, I think we can do more–and we will! Next time, we’ll cover adding another API to really take this project to the next level on our way to hitting our v1.0 General Release!

This file contains bidirectional Unicode text that may be interpreted or compiled differently than what appears below. To review, open the file in an editor that reveals hidden Unicode characters. Learn more about bidirectional Unicode characters

Show hidden characters

	import board
	import gc
	import time
	import busio
	from digitalio import DigitalInOut, Pull
	import neopixel
	from adafruit_matrixportal.matrix import Matrix
	from adafruit_esp32spi import adafruit_esp32spi
	from adafruit_esp32spi import adafruit_esp32spi_wifimanager
	import json
	import display_manager
	# --- CONSTANTS SETUP ---
	try:
	from secrets import secrets
	except ImportError:
	print("Wifi + constants are kept in secrets.py, please add them there!")
	raise
	# local Metro station
	station_code = secrets["station_code"]
	historical_trains = [None, None]
	# --- DISPLAY SETUP ---
	# MATRIX DISPLAY MANAGER
	# NOTE this width is set for 2 64x32 RGB LED Matrix panels
	# (https://www.adafruit.com/product/2278)
	matrix = Matrix(width=128, height=32, bit_depth=2, tile_rows=1)
	display_manager = display_manager.display_manager(matrix.display)
	print("display manager loaded")
	# --- WIFI SETUP ---
	# Initialize ESP32 Pins:
	esp32_cs = DigitalInOut(board.ESP_CS)
	esp32_ready = DigitalInOut(board.ESP_BUSY)
	esp32_reset = DigitalInOut(board.ESP_RESET)
	# Initialize wifi components
	spi = busio.SPI(board.SCK, board.MOSI, board.MISO)
	esp = adafruit_esp32spi.ESP_SPIcontrol(spi, esp32_cs, esp32_ready, esp32_reset)
	# Initialize neopixel status light
	status_light = neopixel.NeoPixel(board.NEOPIXEL, 1, brightness=0.2)
	# Initialize wifi object
	wifi = adafruit_esp32spi_wifimanager.ESPSPI_WiFiManager(esp, secrets, status_light, attempts=5)
	#wifi.connect()
	gc.collect()
	print("WiFi loaded | Available memory: {} bytes".format(gc.mem_free()))
	# --- CLASSES ---
	class Train:
	def __init__(self, destination, destination_name, destination_code, minutes):
	self.destination = destination
	self.destination_name = destination_name
	self.destination_code = destination_code
	self.minutes = minutes
	# --- API CALLS ---
	# queries WMATA API to return an array of two Train objects
	# input is StationCode from secrets.py, and a historical_trains array
	def get_trains(StationCode, historical_trains):
	try:
	# query WMATA API with input StationCode
	URL = 'https://api.wmata.com/StationPrediction.svc/json/GetPrediction/'
	payload = {'api_key': secrets['wmata api key']}
	response = wifi.get(URL + StationCode, headers=payload)
	json_data = response.json()
	del response
	except Exception as e:
	print("Failed to get data, retrying\n", e)
	wifi.reset()
	# set up two train directions (A station code and B station code)
	A_train=None
	B_train=None
	# check trains in json response for correct destination code prefixes
	try:
	for item in json_data['Trains']:
	if item['Line'] is not "RD":
	pass
	# if no train and destination code prefix matches, add
	if item['DestinationCode'][0] is "A" and A_train is None:
	A_train = Train(item['Destination'], item['DestinationName'], item['DestinationCode'], item['Min'])
	elif item['DestinationCode'][0] is "B" and B_train is None:
	B_train = Train(item['Destination'], item['DestinationName'], item['DestinationCode'], item['Min'])
	# if both trains have a train object, pass
	else:
	pass
	except Exception as e:
	print ("Error accessing the WMATA API: ", e)
	pass
	# merge train objects into trains array
	# NOTE: None objects accepted, handled by update_trains function in display_manager.py
	trains=[A_train,B_train]
	# if train objects exist in trains array, add them to historical trains
	if A_train is not None:
	historical_trains[0] = A_train
	if B_train is not None:
	historical_trains[1] = B_train
	# print train data
	try:
	for item in trains:
	print("{} {}: {}".format(item.destination_code, item.destination_name, item.minutes))
	except:
	pass
	return trains
	# --- OPERATING LOOP ------------------------------------------
	loop_counter=1
	last_train_check=None
	while True:
	# update train data (default: 15 seconds)
	if last_train_check is None or time.monotonic() > last_train_check + 15:
	trains = get_trains(station_code, historical_trains)
	if trains:
	last_train_check = time.monotonic()
	# update train display component
	display_manager.assign_trains(trains, historical_trains)
	else:pass
	display_manager.refresh_display()
	# run garbage collection
	gc.collect()
	# print available memory
	print("Loop {} available memory: {} bytes".format(loop_counter, gc.mem_free()))
	# increment loop and sleep for 10 seconds
	loop_counter+=1
	time.sleep(10)

view raw code.py hosted with ❤ by GitHub
